Thermal Camera Module
VERYTEK thermal camera modules are designed for B2B customers who need uncooled LWIR infrared imaging modules for OEM integration, UAV payloads, industrial inspection, security monitoring, automotive night vision and embedded vision systems.
This category includes compact infrared camera modules and thermal imaging cores with multiple resolution options, including 256×192, 384×288, 640×512 and higher-resolution configurations. Product options may support imaging, temperature measurement, compact integration, low-power operation and different output interfaces depending on the model.
Use this page to compare suitable thermal camera modules for your application. For OEM or project requirements, contact VERYTEK with your target resolution, lens requirement, interface, operating environment, quantity and project timeline.
-
UE12L 1280×1024 Ethernet Uncooled Thermal Imaging Module
The VERYTEK UE12L is a high-resolution Ethernet thermal imaging module featuring a 1280 × 1024 uncooled VOx detector, 12 μm pixel pitch, and 30 Hz operation. With ONVIF support, RTSP streaming, and H.264/H.265 video encoding, it provides a network-ready thermal imaging platform for OEM cameras and integrated surveillance systems. Additional capabilities include 1–8× digital zoom, image enhancement, motion and intrusion detection, and lens driving.
- 1280 × 1024 resolution with a 12 μm uncooled VOx detector
- 8–14 μm long-wave infrared spectral range
- NETD <40 mK at f/1.0, 30 Hz, and 300 K
- Ethernet output with TCP/IP, HTTP, RTSP, and ONVIF support
- H.264/H.265 video encoding and 1–8× digital zoom
- DC 12 V input; steady-state power consumption ≤2.5 W at 25°C
- 43 × 43 × 56 mm and <250 g, excluding the lens
User Manual：UE12L Ethernet Uncooled Thermal Imaging Module
-
UVG6 Uncooled Infrared Thermal Imaging Module | 640×512 / 12μm
The UVG6 uncooled thermal imaging module integrates a new-generation wafer-level packaged 640×512 VOx infrared detector together with the latest image processing algorithms, delivering clear, stable, and highly detailed thermal images.Featuring an ultra-compact mechanical design, the module measures only 17 × 17 mm.It offers low power consumption, rich interface options, strong expandability, and easy integration, making it ideal for rapid deployment into various compact and lightweight electro-optical systems. Its small form factor helps significantly reduce overall system size while enhancing design flexibility and integration efficiency.The UVG6 module is well suited for a wide range of applications, including handheld thermal imagers, ADAS automobile driving assistance system, public security and surveillance systems, industrial inspection equipment, outdoor observation devices, and other embedded infrared imaging applications.
User Manual_UVG6 thermal imaging module V1.3
-
UVL12 Series Uncooled HD Thermal Imaging Module | 1280×1024 / 12μm
UVL12 Series Uncooled Thermal Imaging Core module is developedbased on 1280×1024 high resolution infrared
detector,featuringsupreme high imaging quality and various of functions,it is reliableand stable which fits in different kinds of
complex environments,meeting the demands of the users for high definition image,highframerate and detection in remote distance.
1.Supports 30Hz/50Hz output.
2.Low power consumption and stable performance.
3.Supports analog HDand various digital interface outputs.
4.Supports ethernet interface output.
5.Solar burn protection for infrared detector is optional.
6.Supports zoom lens control and auto-focus.
-
UVT Series Uncooled Infrared Thermal Imaging Module | 640 × 512 @ 12μm
UVT Series Uncooled IR Thermal Imaging Module is a compact miniaturized thermal imaging solution for space-constrained applications.Adopting latest uncooled infrared detector and image processing algorithms, it offers stable performance, abundant interfaces, small size, light weight and low power consumption.Widely used for UAV optoelectronic pod, security surveillance, outdoor thermal imager integration and secondary development. -
UVH Series Uncooled Infrared Imaging Module | 1280 × 1024
UVH Series Uncooled IR Thermal Imaging Core – built with 1280×1024 high-resolution infrared detector.Features excellent image quality, full-function configuration, and stable operation in complex environments.Satisfies requirements for high-resolution imaging, high frame rate and long-distance detection.Adopts dedicated ASIC design with high cost-performanceSupports all types of uncooled infrared detectorsCompact, lightweight and low power consumptionIntegrated multiple algorithms for clear image and stable operationMass producible for optoelectronic systems, security monitoring, car night vision, IoT and Industry 4.0 -
UVE Series Uncooled IR Thermal Imaging Network Module | 1280 × 1024
Verytek UVE series uncooled infrared thermal imaging network modules come in three resolutions: 1280×1024, 640×512 and 384×288.Adopting 12μm VOx infrared detectors with high refresh rate, the modules feature high performance, compact size, light weight, low power consumption and cost efficiency.Built with advanced thermal image processing algorithms, it provides ultra-clear and fluent thermal imaging quality.Integrated with SoC chip, it supports mainstream network protocols including TCP/IP, HTTP and RTSP, and allows lens and PTZ control.Equipped with standard RJ45 connector, it is perfectly suitable for IPC camera integration and thermal imaging system applications. -
UVS Series Uncooled Infrared Thermal Imaging Core | 640 × 512
The UVS series uncooled infrared thermal imaging cores from Verytek provide a complete thermal imaging solution for a wide range of applications, including compact thermal night vision monoculars, security and surveillance systems, helmet-mounted night vision devices, and integrated electro-optical systems.
This series is compatible with various mainstream uncooled infrared detectors and features rich interface options for flexible system integration. It also supports custom development and functional expansion, making it ideal for integration into diverse thermal imaging devices and electro-optical platforms, as well as applications such as security monitoring, vehicle-mounted night vision, and IoT systems.
UVS6 ：Specificaitons_UVS6 series uncooled thermal imaging module
UVS6 Mipi-IE：UVS6-mipi-IE-UncooledThermalImagingModule -
UVB Series Uncooled Infrared Thermal Imaging Module | 640 × 512 @12μm
UVB Series Uncooled Thermal Imaging Module (384×288 / 640×512, 12μm VOx)
The UVB Series Uncooled Thermal Imaging Module is designed for OEM integration requiring high performance, compact size, and low power consumption. Available in 384×288 and 640×512 resolutions, the module is built on a 12μm VOx infrared detector combined with a proprietary image processing system.
Optimized for SWaP (Size, Weight, Power, and Price), the UVB series is ideal for applications such as UAV payloads, security systems, automotive night vision, and industrial inspection.
-
UVA Uncooled thermal imaging core module | 640×512 @12μm
UVA Series uncooled thermal imaging core moduel
is the thermal imaging solution specially designed for the city safty and family surveillance, the module is light weighted with multiple interfaces,secondary development and features are available for option, it can be used independently or integrated into the customer’s system, and applied for various kinds of ourdoor/ indoor surveillance.
The UVA Series Uncooled Thermal Imaging Core Module is a compact, low-power thermal core designed for city safety and surveillance applications. It features accurate temperature measurement, Ethernet network output, open API integration, and full-temperature digital video streaming for indoor and outdoor monitoring systems.
-
UVR 640/384/256/ LWIR Thermal Camera Module
The UVR series uncooled infrared module is available in 640×512, 384×288, and 256×192 resolutions. It integrates a high-frame-rate 12 μm WLP detector with a second-generation self-developed infrared ISP chip, delivering a balanced combination of performance, compact size, light weight, low power consumption, and cost efficiency. The design fully complies with SWaP (Size, Weight, and Power/Price) requirements for airborne platforms.The UVR series has been delivered in volume and is already deployed in mass-production UAV platforms. It has been integrated by UAV manufacturers and used in large-scale deployments, with stable performance verified across production batches and real-world flight operations. This makes the UVR series a proven and low-risk choice for drone payload integration.The entire series adopts a shutter-less architecture, ensuring smooth and continuous imaging without stutter during flight. Combined with a new-generation infrared-dedicated image processing algorithm, the module produces clear and consistent thermal images suitable for long-duration airborne missions.Multiple digital interfaces are provided, enabling flexible integration with UAV onboard computing and intelligent processing platforms. The module is well suited for standardized UAV payload designs and long-term supply in volume production programs. -
TL640i Uncooled Infrared Thermal Imaging Module | 640×512@12μm
- The TL640i uncooled infrared module is specifically designed for applications where dimensions and power consumption are critical concerns.
- Featuring extreme compactness, lighter weight and lower power consumption, it supports multiple parallel communication and video output interfaces, and provides various lightweight infrared lenses.
- This series of imaging-type products can provide comprehensive infrared imaging solutions for a variety of photoelectric products including small handheld telescopes, helmet night vision devices, light-type unmanned aircraft systems, and driving assistance devices.
- Products for temperature measurement can be applied in many fields like industrial and electrical temperature measurement, security measurement, and machine vision.
-
TL640T Uncooled Infrared Thermal Imaging Module (Temperature Measurement)
- The TK-L640T uncooled infrared module is specifically designed for applications where dimensions and power consumption are critical concerns.
- Featuring extreme compactness, lighter weight and lower power consumption, it supports multiple parallel communication and video output interfaces, and provides various lightweight infrared lenses.
- This series of imaging-type products can provide comprehensive infrared imaging solutions for a variety of photoelectric products including small handheld telescopes, helmet night vision devices, light-type unmanned aircraft systems, and driving assistance devices.
- Products for temperature measurement can be applied in many fields like industrial and electrical temperature measurement, security measurement, and machine vision.
