VERYTEK Products
-
UVE Series Uncooled IR Thermal Imaging Network Module | 1280 × 1024
Verytek UVE series uncooled infrared thermal imaging network modules come in three resolutions: 1280×1024, 640×512 and 384×288.Adopting 12μm VOx infrared detectors with high refresh rate, the modules feature high performance, compact size, light weight, low power consumption and cost efficiency.Built with advanced thermal image processing algorithms, it provides ultra-clear and fluent thermal imaging quality.Integrated with SoC chip, it supports mainstream network protocols including TCP/IP, HTTP and RTSP, and allows lens and PTZ control.Equipped with standard RJ45 connector, it is perfectly suitable for IPC camera integration and thermal imaging system applications. -
UVS Series Uncooled Infrared Thermal Imaging Core | 640 × 512
The UVS series uncooled infrared thermal imaging cores from Verytek provide a complete thermal imaging solution for a wide range of applications, including compact thermal night vision monoculars, security and surveillance systems, helmet-mounted night vision devices, and integrated electro-optical systems.
This series is compatible with various mainstream uncooled infrared detectors and features rich interface options for flexible system integration. It also supports custom development and functional expansion, making it ideal for integration into diverse thermal imaging devices and electro-optical platforms, as well as applications such as security monitoring, vehicle-mounted night vision, and IoT systems.
UVS6 ：Specificaitons_UVS6 series uncooled thermal imaging module
UVS6 Mipi-IE：UVS6-mipi-IE-UncooledThermalImagingModule -
UVB Series Uncooled Infrared Thermal Imaging Module | 640 × 512 @12μm
UVB Series Uncooled Thermal Imaging Module (384×288 / 640×512, 12μm VOx)
The UVB Series Uncooled Thermal Imaging Module is designed for OEM integration requiring high performance, compact size, and low power consumption. Available in 384×288 and 640×512 resolutions, the module is built on a 12μm VOx infrared detector combined with a proprietary image processing system.
Optimized for SWaP (Size, Weight, Power, and Price), the UVB series is ideal for applications such as UAV payloads, security systems, automotive night vision, and industrial inspection.
-
UVA Uncooled thermal imaging core module | 640×512 @12μm
UVA Series uncooled thermal imaging core moduel
is the thermal imaging solution specially designed for the city safty and family surveillance, the module is light weighted with multiple interfaces,secondary development and features are available for option, it can be used independently or integrated into the customer’s system, and applied for various kinds of ourdoor/ indoor surveillance.
The UVA Series Uncooled Thermal Imaging Core Module is a compact, low-power thermal core designed for city safety and surveillance applications. It features accurate temperature measurement, Ethernet network output, open API integration, and full-temperature digital video streaming for indoor and outdoor monitoring systems.
-
MV Series Infrared Thermal Monocular
Thermal Imaging Monocular for Night Vision, Outdoor Observation, Security & Rescue
The handheld infrared thermal monocular is a compact and lightweight thermal imaging device designed for night vision and long-range detection. It integrates thermal imaging, a built-in laser rangefinder with up to 1000 m measurement capability, Wi-Fi connectivity, and photo/video recording, making it suitable for outdoor observation, security patrol, search and rescue, and wildlife monitoring.
Verytek-MV-series-operation manual-User manual-v1.pdf
MV Series Handheld IR Monocular.pdf
Video View:
-
UVR 640/384/256/ LWIR Thermal Camera Module
The UVR series uncooled infrared module is available in 640×512, 384×288, and 256×192 resolutions. It integrates a high-frame-rate 12 μm WLP detector with a second-generation self-developed infrared ISP chip, delivering a balanced combination of performance, compact size, light weight, low power consumption, and cost efficiency. The design fully complies with SWaP (Size, Weight, and Power/Price) requirements for airborne platforms.The UVR series has been delivered in volume and is already deployed in mass-production UAV platforms. It has been integrated by UAV manufacturers and used in large-scale deployments, with stable performance verified across production batches and real-world flight operations. This makes the UVR series a proven and low-risk choice for drone payload integration.The entire series adopts a shutter-less architecture, ensuring smooth and continuous imaging without stutter during flight. Combined with a new-generation infrared-dedicated image processing algorithm, the module produces clear and consistent thermal images suitable for long-duration airborne missions.Multiple digital interfaces are provided, enabling flexible integration with UAV onboard computing and intelligent processing platforms. The module is well suited for standardized UAV payload designs and long-term supply in volume production programs. -
TS Thermal sight – thermal scope
Thermal sight,thermal scope,thermal rifle scope,thermal weapon sight,
TS series thermal sight features fine image and compact
design, and is dedicated for night vision and sighting;
the rugged design offers not only superior flexibility and
anti-shocks ability, but also convenience in operation and
installation at the same time, making it an ideal choice for
the hunting at night and outdoor applications.TS Thermal Sight is a compact thermal imaging sight with 384×288 or 640×512 resolution, designed for night detection, surveillance, and outdoor operations. It delivers reliable thermal performance with flexible lens options, real-time connectivity, and rugged portability.
Product Specification: TS Series-EN OEM.pdf
Video View: https://youtu.be/_7u0DunTI4Y
TS unboxing video: https://youtu.be/C1SzKdkiaY4
TS6-50 Outdoor Video: https://youtu.be/hjVXHGsy2Z4
-
TL1280T Uncooled IR Thermal Imaging Module (Temperature Measurement)1280×1024
The TL1280T uncooled infrared module is a next-generation LWIR thermal imaging module designed for professional OEM integration and high-performance thermal camera development. Built with self-developed uncooled infrared detectors, it delivers 1280-resolution large-array thermal imaging in an ultra-compact 29 mm × 29 mm form factor with a lightweight 24.5 g design.
With its compact size, low weight, and high-resolution thermal imaging capability, the TL1280T is ideal for handheld thermal cameras, UAV payloads, security systems, industrial inspection devices, and other applications that require lightweight, high-quality infrared imaging modules. Its advanced design and expert engineering support make it a strong choice for developers seeking reliable uncooled LWIR module solutions.
-
TL1280i Uncooled Infrared Thermal Imaging Module (Imaging)
The TL1280i is a high-resolution uncooled infrared thermal imaging module designed for professional users, thermal camera manufacturers and OEM system integrators. It features a self-developed 12 μm VOx uncooled infrared detector with a 1280×1024 resolution, delivering megapixel-class thermal images with enhanced target detail and scene visibility.
Measuring only 29 mm × 29 mm and weighing approximately 24.5 g, the TL1280 combines high-resolution infrared imaging with a compact, lightweight design. It is suitable for thermal imaging systems with strict size, weight and integration requirements, including UAV thermal payloads, security surveillance systems, electro-optical equipment and compact infrared imaging devices. Backed by an experienced R&D team, the TL1280 provides a reliable and integration-friendly solution for developing next-generation high-resolution thermal imaging products.
-
TL640i Uncooled Infrared Thermal Imaging Module | 640×512@12μm
- The TL640i uncooled infrared module is specifically designed for applications where dimensions and power consumption are critical concerns.
- Featuring extreme compactness, lighter weight and lower power consumption, it supports multiple parallel communication and video output interfaces, and provides various lightweight infrared lenses.
- This series of imaging-type products can provide comprehensive infrared imaging solutions for a variety of photoelectric products including small handheld telescopes, helmet night vision devices, light-type unmanned aircraft systems, and driving assistance devices.
- Products for temperature measurement can be applied in many fields like industrial and electrical temperature measurement, security measurement, and machine vision.
-
TL640T Uncooled Infrared Thermal Imaging Module (Temperature Measurement)
- The TK-L640T uncooled infrared module is specifically designed for applications where dimensions and power consumption are critical concerns.
- Featuring extreme compactness, lighter weight and lower power consumption, it supports multiple parallel communication and video output interfaces, and provides various lightweight infrared lenses.
- This series of imaging-type products can provide comprehensive infrared imaging solutions for a variety of photoelectric products including small handheld telescopes, helmet night vision devices, light-type unmanned aircraft systems, and driving assistance devices.
- Products for temperature measurement can be applied in many fields like industrial and electrical temperature measurement, security measurement, and machine vision.
-
TL384i Uncooled Infrared Thermal Imaging Module (Imaging)
TL384i uncooled infrared module has made further technical breakthroughs, redefining the new standard of weight, dimensions, and power consumption (SWaP³) in the infrared OEM module industry. It meets professional needs in the fields of routine inspection, security, search and rescue, and industrial monitoring and provides excellent miniaturized high-resolution solutions for consumer products.
