Equipped with a 12μm VOx detector, resolution of 640×512, supporting super-resolution up to 1280×1024.
Capable of distinguishing the temperature difference of 0.025°C, with high temperature measurement accuracy and more-detailed thermal images.

Standard 25° lens, with optional wide-angle, telephoto, and super telephoto lenses.
Support macro lenses, flexible for diverse scenarios.

Android operating system, more convenient to operate
Support intelligent image stabilization, making temperature measurement images more stable
Support laser rangefinding and area measurement
Support up to 25 points/lines/areas to analyze more temperature details in the screen

Thermal Imaging

Detector Type	Uncooled infrared detector
Infrared Resolution	640×512
Pixel Size	12μm
Spectral Band	7.5-14μm
NETD	＜25mK (25°C,F1.0)
Frame Rate	25Hz
Lens Focal Length	Standard lens: 17.7mm; super telephoto lens: 60.9mm; telephoto lens: 31.5mm; wide-angle lens: 9.5mm; macro lens (0.2×): 13mm; super macro lens (0.4×): 14.8mm.
FOV	Standard lens: 25°×20°; super telephoto lens: 7°×5.6°; telephoto lens: 14°×11.2°; wide-angle lens: 45°×36°.
IFOV	Standard lens: 0.68mrad; super telephoto lens: 0.2mrad; telephoto lens: 0.38mrad; wide-angle lens: 1.26mrad; Macro lens: One pixel corresponds to 60μm; super macro lens: One pixel corresponds to 30μm.
Focusing Mode	Electric micro focus, manual focusing, one-button center focus, automatic center focus, single-touch automatic focusing, laser-assisted focus
Measurement Range	-20°C~+150°C, 100°C~650°C; optional: 400°C~+1500°C
Measurement Accuracy	±2°C or ±2% of readings, whichever is greater

Imaging Display

Display	5.5-inch LCD touch screen, resolution 1920×1080
Visible Light Camera	13 megapixels
Digital Zoom	1× ~ 10×
Palettes	19 options
Image Mode	Infrared, visible light, PIP, dual-spectrum fusion
Temperature Width Stretch	Support

Measurement and Analysis

Analysis Functions on the Device	Support up to 25 movable points, lines, frames, circles and polygons, and up to 5 preset modes
Laser Rangefinding	Support
Area Measurement	Support
Hygrothermograph	Support
Position	Support
Temperature Difference Analysis	Support
Trend Analysis	Supports temperature trend recording and analysis.
Image Freezing	Support
Analysis Report	PDF format. Support editing and template importing on the PC client.
Supporting Software	PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP)

Image Storage

Storage Medium	Standard 64GB MicroSD. Support SD, SDHC, and SDXC, up to 2TB.
Text Notes	Support
Voice Annotation	Support

Video Functions

Radiation Infrared Video Recording	Support compressed full radiation video recording (.irv), up to 15Hz video recording
Non-radiation Infrared or Visible Light Video Recording	Standard MP4 video recording

System Functions

Intelligent Routine Inspection	Support. General task package import and editing, standard and automatic naming of images
Communication Protocol	Wi-Fi, Bluetooth, USB

Others

Battery	9000mAh lithium-ion battery, field-replaceable, fast charging
Battery Life	Continuous operating time ≥ 3 hours (depending on the actual environment and service conditions)
Charging Mode	USB Type-C or desktop charger
Interface	USB3.0 Type-C, SD card, SIM card, Mini HDMI
Tripod Socket	UNC 1/4-20 interface for tripod
Operating Temperature	-15°C~+50°C
Operating Humidity	10%~95% (non-condensing)
Storage Temperature	-40°C~+70°C
Ingress Protection Rating	IP54
Shock and Vibration	Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
Weight and Dimensions	About 1.3kg (with battery), 278×116×113mm
Authentication	CE/RoHS/CMA, etc.
Packing List	Thermal camera, manual, calibration certificate, quick operation guide, data download card, certificate of qualification, multi-country adapter,, USB data cable, lithium-ion battery×3, portable bag, charging cradle, HDMI cable, hand strap, backpack strap, SD card, charging stand, standard lens.
