Equipped with a 640×512 customized band-pass filter detector to eliminate stray light interference; capable of distinguishing a temperature difference of 0.023°C, capturing gas microleakage.
Spatial resolution as low as 0.63mrad, providing wider working distances or better gas details.

Simultaneous observation of thermal imaging and visible light to easily locate gas leaks
High accuracy of temperature measurement, easy to meet the dual tasks of gas leakage detection and temperature measurement
5-inch touch screen+ complete analysis functions, easy to facilitate routine inspection tasks

Ex ic IIC T4 explosive-proof rated, suitable for security applications in explosive-proof applicationsuch as oil and natural gas routine inspections.

Thermal Imaging Parameters

Detector Type	Uncooled infrared detector
Infrared Resolution	640×512
Spectral Band	7.0-8.5μm
Gases Detectable	Methane (CH₄), Sulfur Dioxide (SO₂), Freon (R-134a, R-152a) and other gases
Pixel Size	12μm
Thermal Sensitivity (NETD)	23mK
Spatial Resolution (IFOV)	0.63mrad
Image Frequency	30Hz
Lens Focal Length	19mm
Field of view (FOV)	23°×18°
Object Temperature Range	-20°C~+120°C
Temperature Accuracy	±2% or ±2°C

Camera Functions

Temperature Measurement Mode	Center point/Hot and cold spot tracking and temperature display
Customized Measurement on Points, Lines, and Areas	Movable points/lines/areas; up to 10 points, 10 areas, and 10 lines
Measurement Unit	Celsius, Fahrenheit, Kelvin
Emissivity Settings	0.01~1.00, step size 0.01
Ambient Temperature Settings	-10°C~+50°C, step size 1°C
Distance Settings	1~20m, step size 1m
Image Mode	Infrared, visible light, dual-spectrum fusion, PIP
Palettes	10
Temperature Alarm	Available
Alarm Type	Image Alarm
Temperature Width Stretch	Manual/Auto temperature range
Laser Pointer	Available
Visible Light Camera	5 megapixels
Video/Photo Storage	XX-IR.jpg (Infrared image with temperature data) and XX-DC.jpg (visible-light image); videos without data.
Voice Note	Available
Language	English, Japanese, Poland, Russian, Korean, Hungarian, Bap, German, French,Spain, Italy, Turkey, and Traditional Chinese
Display Size	3.5-inch touch screen (480×640)
Image Naming	Auto/manual naming, naming by scanning QR code
Memory Card	Standard 32GB Micro SD card
Battery Type	Rechargeable and detachable lithium-ion battery
Power Supply	USB TypeC
Connecting Method	USB, SD card, Wi-Fi (AP mode or networking mode)
Battery Charging Time	About 3h
Battery Operating Time	About 3h
Cloud Services	Transfer shooting data to a cloud drive, share data and perform secondary analysis at multiple clients; support automatic time synchronization
Power Management	Automatic shutdown: 5 minutes, 10 minutes, 20 minutes, never

Others

Analysis Software	PC & App
Tripod Support	Available
Operating Temperature	-10°C~+50°C
Storage Temperature	-20°C~+60°C
Relative Humidity	10%~95%, non-condensing
Drop Protection	2m
Ingress Protection Rating	IP54(IEC 60529)
Shock and Vibration	Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
Dimensions	258.4×105.1×102.3(mm)
Weight	About 670g
Certificaitons	CE/ROHS, etc.
Packing List	5V 3A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger, calibration certificate, package list

RG600C OGI Handheld Camera
