FC460A Observation Thermal Bullet Camera

FC4A thermal bullet camera equipped a 640×512, 12 μm pixel pitch thermal detector with a focal length up to 75mm.
It supports tripwire/intrusion detection.
It can be used for perimeter protection in critical facilities.

FC460A Observation Thermal Bullet Camera

Adopting the latest 12μm uncooled infrared detectors, integrated with advanced infrared imaging algorithms for better image quality.

Support tripwire/intrusion detection, as well as intelligent detection of fire point.

Supports 35mm/55mm/75mm fixed-focus infrared lenses to meet long-range detection needs.

Support ONVIF, provide SDK&demo for development; provide NVR and VMS software for application.

Thermal Module

Smart Function

Fire Detection	Support
VCA	Support Line Crossing & Intrusion detection
2-Way Audio	Support
Linkage Action	Video/ Snapshot/Email/Alarm output/sound and light alarm

System Interface

Power	DC 12V±25%/POE(802.3at)
Network	1 RJ45 10M / 100M self-adaptive Ethernet port
Audio	1 in/1 out
Storage	Micro SD memory（maximum 256G）
Reset	Support
Serial Port	1 channel RS485, can support Pelco protocol
Analog	1 BNC
