SilentW-U6 Series Infrared Panoramic Camera

  • SilentW-U6 is a solution for large area monitoring by using a 12μm 640×512 thermal detector and capturing 360° panoramic image.
  • SilentW is able to detect mulitple objects at same time and can be widely used in oil/gas fiels and mines to make a comprehensive security solution.

SilentW-U6 Infrared Panoramic Camera

Feature

logo

Industry-Leading Infrared Detector

Adopts the latest 12μm uncooled infrared detector or high-performance MWIR cooled detector, and advanced infrared image algorithms to ensure clear imaging at greater distances.
logo

360° Panoramic Surveillance

Detects a full circle in approximately 2 seconds and delivers real-time panoramic video images, enabling comprehensive visual monitoring without blind spots.
logo

Multi-Target Detection

apable of simultaneously detecting&tracking up to 128 targets, detection range up to 8km.
logo

Link with PTZ Camera

Easy calibration, link with dual-spectrum PTZ camera to track the target. Using zoom lens to view more details from long distance.
logo

Intelligent Detection Algorithm

Deep learning AI algorithm to recognize human, vehicle, ship, and UAV targets.
logo

Low Power Consumption

Low power cunsumption, can be powered by solar, reduce the needs of infrastructure.
SilentW-U6 Series-1 SilentW-U6 Series-2 SilentW-U6 Series-3 SilentW-U6 Series-4

Specification

Thermal Module
Detector Type VOx, uncooled FPA detectors
Spectral Range 8~14μm
Resolution 640×512
Pixel Pitch 12μm
Focal Length 55mm/75mm
PTZ
Pan 360° continuous,180°/s or 133°/s
Tilt -20°~+35°,motorized
Scan mode Panorama Scan
Smart Function
Fire Detection Support
VCA Motion Target Detection/AI Detection
Linkage Action Linkage of PTZ camera
System Interface
Power DC 30V 5A
Network 1000M Ethernet port
General
Work Environment -40℃~+70℃
Protection IP66
Power Consumption ≤30W
Dimenstion(mm) 327×260×377
Weight 20kg

Application Scenarios



Perimeter Surveillance
Perimeter Surveillance


Important Area Perimeter


Nature Reserve
Nature Reserve


Oil and Gas Pipelines
